Full spec sheet
Specs by
Frame
Double Butted Alloy E-Bike Frame, Internal Cables
Fork
Aluminum w/ Light Mount, 12x100 TA, PS
Headset
Tapered 1-1/8"- 1.5",(ZS44/28.6 | ZS56/40)
Stem
Norco Aluminum, 70mm (S/M) -80mm (M/L), 17deg Riser, 31.8 clamp
Handlebar
Norco Custom High Rise City Bar, 660mm, 60mm Rise, 30Deg Backsweep
Grips
Dual Density Ergonomic Single Lock, 133mm Length
Brakes
Shimano
Brake Levers
Shimano
Shifters
Shimano CUES
Crankset
Prowheel Alloy, 42T, 165mm
Bottom Bracket
Hyena ST-SQ-1 BB, T47
Chain
KMC
Cassette
Shimano CUES
Rear Derailleur
Shimano CUES
Wheels
650b
Hubs
Formula, Hyena MRC-E250 Hub Motor, 36V, 250W, 40Nm, 12x138mm Sloted TA, HG, 36h, 6-bolt
Tires
Kenda
Seatpost
Norco Rigid, 31.6mm
Saddle
Scene Comfort Saddle w/Elastomer Suspension, 225mm W x 269mm L
Motor
250W 40Nm hub-drive
Battery
250Wh
Display
Hyema CE-03, 3 buttons, LED indicators, Bluetooth connection, Cable length 600mm
